This product is suitable for metal mine, non-coal mine hill, slope, shaft, water diversion hole, tunnel, subway and other projects
Features:
1. A variety of models can be customized according to customer requirements
2. Strong,high working efficiency, stable operation
3. Large bearing capacity, comfortable operation
4. Hydraulic cylinder: hydraulic double top dump, double chrome plated cylinder, not easy to rust long service life
5. Axle: low speed ratio, large torque, strong load capacity, stable quality
| Product number | X J-7 ton rear drive dump truck |
| Engine model | Yunnei 4102 diesel engine (naturally aspirated) |
| Engine power | 70KW/95HP |
| Gearbox Model | Dongfeng 145 gearbox/high and low speed |
| Axle Model | Increased weight 1080 drive rear axle (145 main reduction) |
| Carriage size | 3000mm*1800mm*600mm(length*width*height) |
| Carriage volume | 3.25m³ (flat pack) |
| Standard load | 7000KG |
| Carriage steel plate thickness | Bottom 8mm side 6mm |
| Tire brand/model | "Kunlun" 750R16 mining steel wire tire (rear left and right double wheels) |
| Frame model | 180*60*6 (manganese steel welded frame) |
| Hydraulic cylinder model | 115*900 (diameter*stroke) |
| Dumping method | Rear double top dump |
| Number of spring plates/model | Front 10 pieces, rear 10 pieces + 6 pieces 70mm*10mm |
| Drive mode | Rear axle drive |
| Braking method | Air brake |
| Steering method | Hydraulic steering gear steering |
| Exhaust gas treatment | Water filtration and purification (patented) |
| Driving style | Left-hand drive |
| Cab | Mine lifting safety roof |
| Vehicle size | 4870mm*1850mm*2110mm(length*width*height) |
| Gear shifting method | Gear line gear |
| Front and rear wheelbase | 2585mm |
| Vehicle weight | 3530KG |
| Cab height | 2110mm (ground to the highest point of the cab) |
| Carriage height | 1650mm (ground to highest point of carriage) |
| Carriage lifting highest point | 3280mm |
| Minimum ground clearance | 180mm |
| Maximum climbing angle | 14° (heavy vehicle climbing) |
| Remark: | The size of the car box can be customized; |
