Chassis model

QL1096NKHACY

Chassis brand

Isuzu

Fuel typel

Diesel

Driver seat

Left hand drive

Gear box

Mechanic and Automatic

Driving type

2x4. 2 rear tire

Driving Mode

4 type

Engine Model

4KH1N6MD

Wheelbase

3365

Brake type

4 wheel brake

Engine power/displacement

103KW/2999ml

Tire model

7.50R16LT 16PR

Maximum operating height

28M

Vehicle size

6050*2050*2780

Maximum operating range

17M

Total mass

9100

Working height at maximum working range

26M

Cylinder

Xuzhou Yanhuang

Working range at maximum working height

5M

Outrigger span (mm)

5360/5260

Boom type

8 sections synchronous extension

(Thickness: 3mm for the first 4 sections and 4mm for the last 4 sections)

Outrigger structure

Double Leg X Type

Arm material

Baosteel 960

Boom heave angle

-10/+75°

Boom structure

18 arm

Hydraulic lock

Yangzhou Zhongmei Hydraulic YS6-03H

Basket size

1600*700*1000

Nylon Sliders

(Xuzhou Black and White Dragon)

Hydraulic reel

Shanghai Quantuo

Electronic control system

Hunan Cyber Hunan Cyber remote control distance 150 meters

On-board valve

Beijing Shengweihua (joint venture)

TPSL3-DSE12-04-X2-01

How to operate

Electric control, remote control

Leveling form

Static automatic

Leveling device

Hydraulic oil pipe leveling

Turntable rotation form

360°

Slewing support

Jiangsu Changzhou Kesen S19-116-LH-250A-REVA

Rotation form

360°

Working platform rated

200KG

basket rotation

160°

Back arm form

Taiwan leaf chain

Arm form

Taiwan leaf chain

Standard

Cab, air conditioning, weighing, wind speed sensor，lifting height limiter
