Product Description
Equipped with Fast gearbox, it is powerful, fuel-efficient and efficient. High-strength frame with large rear axle, strong load-bearing capacity. Narrow rear axle, strong passability. Suitable for construction of bridges, tunnels, culverts and other projects, suitable for narrow roads in rural areas and urban villages.
Product features
1. Strong loading and unloading capacity. The mixing drum has a large geometric volume and a large installation angle.
2. Even mixing without segregation;
3. High wear resistance. Wear-resistant alloy steel materials are selected and welded automatically;
4. It complies with national emission standards and can be registered and driven on the road nationwide;
5. Beautiful appearance, high-end and comfortable cab;
6. Strong escape ability, equipped with differential lock;
7. Applicable to construction sites, water conservancy and other engineering construction;
Sinotruk series Homan 9-square mixer truck chassis parameters |
Vehicle Brands: | Sinotruk Homan series mixer truck | Vehicle name: | Concrete mixer truck |
engine: | WP4.6NQ220E61A intercooler booster | Total mass: | 24500 (kg) |
Dimensions: | 8 57 0X2 420 X3 8 5 0 | the color of car: | Yubai |
curb weight | 1 0315 (kg) | Rated quality: | 1 3 990 (kg) |
Drive mode: | 6X 4 drivers | Wheelbase: | 3400 X 1350 |
Number of axes | 3 axis (6X 4 ) | Maximum speed: | 8 0(km/h) |
Variable box: | Fast 10 speed gearbox(10JS90A-B) | Front and rear axles: | Front axle 5.5T Rear axle 11T bottom speed cargo axle |
Large frame: | (860-800)X280X(8+6) double-layer large rack | Tire specifications: | 1000R20 18PR |
Front and rear track: | 1870 X 1750 X 1750 | Number of tires: | 10 (steel tire) |
Chassis emission standards: | GB17691-2018 National VI | Stirring volume: | 6 . 77 m3 |
Quota of passengers: | 3 people | Fuel type: | diesel fuel |
Vehicle Advantage: Lightweight | Standard model, not overweight, in line with the new national regulations and policies, suitable for areas where the control exceeds the control limit, and can realize multiple pull materials |
basic configuration: | Remote control key damping adjustment quick drop headlight LED electric window constant temperature air conditioner central control lock sunshade single sleeper throttle conversion |
Mixer truck configuration |
Tank material: | High-strength and wear-resistant alloy steel B520JJ steel is used, with a thickness of 6mm, which increases the life of the tank by more than 3 times, and is treated with shot blasting and anti-rust. |
Blade material: | 6# thick alloy steel (adding wear-resistant strips to improve service life) | Head material: | 8# thick double head alloy steel |
Reducer: | German PMP reducer has strong bearing capacity and low failure rate | Hydraulic system: | Rexroth _ /Danfoss, the system eliminates segregation, and the residual rate is low |
Tug: | Use large-size tugboats to improve the stability of tank operation | cooling system: | Smart radiator 20 liters |
Feed rate: | Feed speed m³ /min≥3 | Output speed: | Output speed m³ /min ≥ 2 |
water supply system: | 5 00 L enlarged water tank for air pressure water supply | Operation method: | Left and right sides and cab tripartite operation |
Unloading range: | 180 ° up and down left and right height adjustment | safety devices: | Add leakage device |
Features: | The top-mounted full tooling guarantees that the mixing drum adopts the most advanced double-logarithmic German spiral curve design in China, and the optimal configuration ratio of the diversion hole and the mixing plate makes the rotation of the mixing drum more stable, the concrete homogeneity is better, and the feeding and discharging speed is improved. Fast, no segregation, low residual rate, longer service life. |
